ZRB-101: 10 TON 1.5" RAM

The Zinko ZRB-101 delivers 10 tons of single-acting force in confined areas where standard cylinders cannot fit. Standing 3.47" tall when collapsed, it provides a generous 1.50" stroke to ensure ample lifting height from narrow clearance zones. This 9 lb cylinder operates reliably in any position, featuring an integrated grooved plunger end with threaded holes for mounting optional tilt saddles. It comes standard with a 3/8" NPT fast-flow coupler and protective dust cap. With the appropriate accessories, the unit pairs seamlessly with hand, air, or electric hydraulic pumps.

Mutiple application for many different fields that require single-acting cylinders.

• Capacity: 10 Ton
• Stroke: 1.50"
• Oil Capacity: 3.35in³
• Min Ht: 3.46"
• Max Ht. 4.96"
• Outside Diameter (in): 2.71"

• Cylinder Effec. Area: 2.24in²
• Ship Wt.: 9 lbs.
