HYDRAULIC TOE JACK - 12 TON MODEL: ZHC-12V
$1,175.44
Availability : In Stock
Shipping : Ships same-day or 1-2 business days
Features:
1. 360 degree turn lever socket for operation at any direction.
2. Low toe height is ideal for use where clearance is tight.
3. Designed for fine adjustments. Ideal for delicate work such as installation of precision machines.
4.Welded steel construction prevents oil leakage and a special heat treatment that reduces metal fatigue.
- Specifications
- Support & Dowloads
This is the best choice for lifting heavy machinery and cargo, especially when installing industrial machinery, relocating shipyard equipment, or during bridge and plant construction.
Specifications:
- Capacity(Toe/Head): 12/24 Ton
- Min Ht (Toe/Head): 1.10"/12.79""
- Max Ht (Toe/Head): 6.81"/18.50"
- Ram Lift: 5.70"
- Toe Area: 3.34" x 2.36"
- Base Area: 11.41" x 8.85"
- Ship Wt.: 88 lbs.
